4 x 165mm (6.5 “) custom woofers with 38mm (1.5”) coil
Neodymium B&C compression HF driver with 36mm (1.4″) spout and 64mm (2.5″) coil
Large format FBT waveguide with 90° (H) x 20° (V) dispersion
Frequency response from 65Hz to 20KHz
Class-D 600Wrms for LF and 300Wrms for HF amplifiers with switch mode power supply
DSP processor with 8 equalization presets
Control panel with XLR input and link, volume, presets, filter-HP, ground-lift
Neutrik PowerCON TRUE1 IN and LINK power connectors
Cabinet in 12mm (0.5″) birch plywood with anti-scratch varnish. Handles with rubber inserts and rubber-coated sides to protect the cabinet from bumps and scratches.
Side suspension hardware with integrated setting pins, inclination between adjacent cabinets from 5° to 20° in 5° steps. Possibility of vertical and horizontal installation through dedicated flybars.
Wide range of accessories for suspension, pole-mounting or ground-stacking.
Ideal for both live applications, assisted by one or both subs of the VHA range, and for fixed installations
